Working with the awesome team at UNBND we built a multi sensor node that sent data to an a unity app to generate NFTs.

Above: Final format Raspberry Pi sensor with camera mic and distance sensors.

About

This project combines sensors procedural and generative digital art with NFTs. It was planned to be a live event (2-4 hours) and an on premise activation for 2 weeks in multiple locations.

Project Status: ON HOLD

Due to COVID-91 the project has be placed on hold. The work completed included a working Proof of Concept sensor and artwork component.

Here you will find all work completed to this point. What is missing is the artwork's creative direction and treatment which was to be coordinated with a featured NFT artist who was TBD at the time of writing.

Tech Flow

This information architecture diagram how the technology flow from the sensors to the app and and back. This diagram represents one raspberry pi (nodeJS) and one art app (Unity) connected via websockets.

Sensors

Raspberry Pi and sensor setup

Connecting to Raspberry Pis

The existing raspberry pi can be connected to with the following command

Osx

$ ssh pi@raspberry.local

Then enter the password

Windows

$ ssh pi@raspberry.locla

Then enter the password

Troubleshooting

If you cant connect ensure SSH has been enabled in the raspi-config settings and that you have the correct host name. If you dint have a hot name you can just use the Pi’s ip address wich can be found with the command $ ifconfig.

Software

There are two main parts to this project the server and the client. The server sits on each raspberry pi and is a socket server that the client connects to. It will transmit the sensor data to all clients when called for. The client is a web socket client that connects to the host name or ip and sends a message command for each sensor which in return the servers will send back sensor data. The commands are as follows:

‘cam’ - requests the camera data

‘dist’ - requests the ultrasonic distance data

‘Sound’ - requests the sound data from the mic

Server

About

This component is a node.js application which uses websockets to establish a web socket server for clients to connect to.

Clinet

About

This component is a Unity application but can be any language that uses web sockets. It uses websockets to establish a web socket client to send custom messages and then receive sensor data.

Hardware

The hardware and sensors component of this is modular and is based on the the following:

1. 1 x Raspberry pi 4 (include)
2. 1 x Raspberry Pi camera either normal or for low light the NOIR (included with spares and variations)
3. 1 x Ultrasonic sensor HC-SR04 (2-400cm) or HC-SR5 (3-500cm) (included with spares and variations)
4. 1 x usb microphone (or usb audio interface) (included with spares and variations)


Other hardware requirements include:

1. Raspberry Pi camera Housing (included)
2. Wall mount
3. USB-C Power supply
4. WiFi router and connection
5. GPIO out for testing (included)
6. Heat sicks
7. Micro SD card

Raspberry Pi Setup Requirements

This project assumes you have the following skills:

1. Raspberry Pi - Raspberry pi or linux experience
2. Electronics - read schematics and understand electronic foundations
3. Network skills - SHH and connectivity required
4. Git - clone and ssh keygen required

Build and Setup Instructions

1. Install latest Rasperian on a 32Gb SD card
2. Run typical Raspberry Pi Setup with
   $ sudo raspy-config
3. Set new Password
4. Set hostname
5. Expand drive
6. Set root mode to password command line (not desktop)
7. Set WiFi
8. Enable SSH
9. Copy SSH keys if you need to dev on the Pi
10. Enable camera
11. Run Raspberry Pi Upgrade
12. Run apt-get update
13. Install Git
14. Install Node
15. Clone tt socket-server repo
16. run
    $ npm install
17. Connect hardware
18. R Pi NOIR Camera and setup then test it works
19. Mic and setup then test it works
20. Ultrasonic sensor and setup then test it works
21. Set up node socket service as a Daemon, PM2 or node Forever
22. Install Forever globally with
    sudo npm install forever -g
23. Edit `sudo nano /etc/rc.local` and add a line before exit eg
    ‘sudo node /home/pi/apps/sensors/socket-server/index.js’
24. Reboot machine with reboot -now
25. The Pi will restart and launch the socket server with the sensor services running ready to be connected via websocket


Websocket Methods

The websocket runs on port 8080 so to connect you need to use the address or host and port number. For example.

ws://raspberry:8080

Then from the artwork app, Unity for example connect to the socket and send a message then hangel the response.

Send Sensor Message in C#

ws.Send("cam"); // get camera sensor data

ws.Send("audio"); // get sound sensor data

ws.Send("dist"); // get distance sensor data

AUDIO_EVENT = "AUDIO_EVENT",

DISTANCE_EVENT = "DISTANCE_EVENT",

CAMERA_EVENT = "CAMERA_EVENT";

Receive Sensor Message in C#

ws = new WebSocket(ip);

ws.Connect();

ws.OnMessage += (sender, e) =>

{

if (e.Data != null){

string targ = ((WebSocket)sender).Url.ToString();

Debug.Log("Message Received from " + targ + ", Data : " + e.Data);

WSMessage jsonData = JsonConvert.DeserializeObject<WSMessage>(e.Data);

if (jsonData.Message == WsEventsType.AUDIO_EVENT){

Debug.Log("[WS - AUDIO_EVENT] Message Received from " + targ + ", Data : " + jsonData.Data);

DataManager.instance.AddSoundSpectrum(jsonData.Audio, targ);

}

}

Sensors

Ultra Sonic Distance Sensor

About

There ware a few options for the sensor and testing in the actual site needed to be done to determined the best suited sensor. However, this POC was created with the most common and tough sensor from the robotics industry called the HC-SR04 and HC-SR05.

Configuration

See Pi setup instructions

Code

The main class for the ultrasonic sensor can be found in the socket-server directory and is called getDistance. This is called from inde.js and props are parsed through such as:

Id: sensor id for differentiation

Interval: int for update frequency

Trigger: pin for trigger

Echo: pin for echo

There are javascript and python scripts to help test the sensor is connected and working if the sensor output data received is null.

Microphone

About

This sensor is a basic USB mic which is very simple to setup (see above). It pulls a frequency spectrum from the mic and parses it rhoguth.

Configuration

See Pi setup instructions

Code

The main class for the mic can be found in the socket-server directory and is called audioSensor.js. This is called from index.js and props are parsed through such as

Id: sensor id for diferentiation

Interval: int for update frequency

NOTE: There are javascript and python scripts to help test the sensor is connected and working if the sensor output data received is null.

Camera

About

This sensor is a standard Raspberry Pic camera which is very simple to setup (see above). It pulls the current frame camera and parses it through as a Buffer object.

Configuration

See Pi setup instructions

Code

The main class for the camera can be found in the socket-server directory and is called videoSensor.js. This is called from index.js and props are parsed through such as

Id: sensor id for differentiation

Interval: int for update frequency

Width: int for height pixels

Height: int for height pixels

Fps: int for framerate

Encoding: JPG, PNG GIF or BMP

Quality: int out of 10

NOTE: There are javascript and python scripts to help test the sensor is connected and working if the sensor output data received is null.

Reference Images

NFT Art Software

Unity

The unity component of this project has three main parts, the web socket, the data manager and the artwork. As the artwork style and treatment was TBD this part has been left out for simplicity.

Software Images

Above: Screen shot of socket server and client. Left screen is the ssh output of raspberry pi socket server printing the sensor data and sending it to unity. Right is the Unity socket client receiving the web socket data.
